SPECIFICATIONS

IDENTITY E301

Accessories
Earphones, Pouch, USB-A to USB mini-B cable, User's Manual (S/W Manual, ConvergenceOne PC Program), Quick Start Guide, AC/DC Charging Adapter (output interface : USB mini-B type)
OSAndroid Froyo v 2.2
CPUSamsung S5PC110, ARM Cortex-A8 1GHz
Storage Internal
External		 8GB NAND Flash Memory
SD Card up to 32 GB (SD/SDHC)
Display Type
Resolution
Color Depth		 7" TFT LCD
1024 x 600 WSVGA
2.6 M Color
Camera Resolution
Auto Focus
Flash
White Balance
Effect		 Front: 1.3M CMOS, Rear: 5M CMOS
Auto Focus
not supported
Auto, Incandescence, Daylight, Fluorescent, Cloudy
Non, Black, Sepia, Negative, Antique, Green, Blue
DMB Frequency
Audio
Video
Supported Format		 Band III (174-240 MHZ), L Band (1450-1492 MHZ) to be added future
models
ISO/IEC 14496-3 ( MPEG-4 ER-BSAC)
ISO/IEC 14496-10 (MPEG-4 Part 10 AVC), ITU-T Rec. H.264
MPEG4, AVI, WMV, ASF, 3GP
Video Codec
Headphone
Output Power
S/N ratio		 H.263, H.264, DivX 4/5/6, XviD, WMV9(VC1), MPEG4
min left 10mW, right 10mW at RL=16O : volume max
min left 5mW, righ5mW at RL=32O : volume max
90dB
Audio Codec
File
Frequency Range
S/N ratio
No. Channels		 AAC, MP3, WMA2/3, AMR-NB/WB, AC3, OGG
MP3, OGG, WMA, 3GP
20Hz - 20KHz
90dB
2
Power Supply AC Adaptor
Battery		 DC 5V-2A
4,400 mAh LI-POLYMER

    IDENTITY E301 FEATURES

    • Internal 8GB NAND Flash Memory
    • 7.0" WSVGA 1.6000.000 Colors TFT-LCD, full metal body
    • Internal Micro HDMI slot / Internal Stereo Speaker / Micro SD Card
    • DIVX, H.264,MPEG4, WMV / 1080P Grade Play
    • Wi-Fi b/g/n, Bluetooth 2.1 + EDR
    • G Sensor, Ambient Light Sensor, Digital Compass
    • Video Playtime 4.5 hours / Standby time 130 hours
    • Google licensed
    • Digital Radio and Mobile TV inside based on DMB/DAB/DAB+
